flangelejehus f/gennemg.aksel
722508DB
13 På lager
13 Aarhus
Specifications
- Bore type
- -
- Cage material
- -
- Design of the housing
- Triangular
- Distance mounting base to centerline bearing (mm)
- 54
- EAN
- 3413520698508
- FAG/INA Part Number
- F 508-WB-L
- Height housing (mm)
- 143
- Housing material
- Grey cast iron
- HS kode
- 84833038
- Inner diameter (mm)
- 35
- Length housing (mm)
- 160
- Leverandørensnavn
- NTN Europe
- Mounting holes distance (mm)
- 140
- Number of fixing holes
- 3
- Outer diameter (mm)
- 80
- Manufacturer
- NTN-SNR ROULEMENTS
- Rings material
- -
- SKF Part Number
- FNL 508 B
- Thread
- M12
- Type of fixing to shaft
- -
- Weight
- 2,3
- Width housing (mm)
- 65,5
- CATALOGUE LINK
- https://www.ntn-snr.com/sites/default/files/2017-03/bearing_housings_en.pdf
